12-24Vdc E1 Dimming European-style touch panel
2 in 1 function: RF wireless control and PWM power output. Power output, lamps can be connected directly, easy and convenient
Touch keys with chord and LED indicator
Save any scene you like, touch 1 key to recall the scene, easy and convenient.
Adopts capacitive touch control technology on the full-color slider, makes LED dimming selection more user-friendly.
The touch panel can be controlled by remote directly or smartphone if add a gateway.
E1 Dimming European-style touch panel
Input Voltage: 12-24Vdc
Current Load: 4A×2CH Max 8A
Output Power: (0~48W...96W)×2CH Max. 192W
Working Temp.: -30℃～55℃
Package Size: L113×W112×H50(mm)
LED Dimmer E1
