LED Strip Light Guide
Common questions about this type of product, answered against this model’s own options. For full figures see the specification above or the spec sheet for this model.
Which controller does this LED strip light need?
Addressable LED strip lights take a data signal, so they need an SPI (pixel) controller that supports this IC — an ordinary RGB controller will not drive them. Data flows one way: connect the controller to the input end marked with the arrow.
Wiring addressable LED strip lightsDo I need power injection?
5 V addressable LED strip lights lose voltage fastest, so longer runs need power fed in at both ends and at intervals along the run; 12 V and 24 V versions carry further. Keep the data line short between controller and first pixel.
Choosing an addressable LED strip lightWhich waterproof rating should I choose?
Available on this model:
Underwater IP68 - Adhesive Back · Outdoor Silicone Tube IP67 - With Brackets · Surface Glued IP65 - Adhesive Back · Non-Waterproof IP20 - Adhesive Back. IP20 is for dry indoor use, IP65 handles splashes, IP67 suits outdoor and wet areas, IP68 is for continuous submersion.
Choosing a waterproof ratingCan I cut it to length?
Yes. Cut only on the marked cut lines between the copper pads — the cut interval for this model is on its spec sheet. Rejoin with solder or a solderless connector.
Cutting LED strip lights · we can also cut to length and fit your connector before shipping:
custom LED strip light assembly.
What size power supply do I need?
Will it fit an aluminium profile, and how dense are the LEDs?
PCB width
10mm (0.39in). Choose a profile whose inner width is at least the PCB width; denser LEDs give a smoother line close to a diffuser.
LED aluminium profilesComplete your setup
Picked for this model from items in stock.
Controllers and dimmersFor addressable LED strip lights at 12 V
Connectors and leadsThree-pin data, 10mm matches first, plus waterproof connectors
Aluminium profilesClosest inner width to a 10mm LED strip light first
Silicone LED neon diffusersTurns the LED strip light into a continuous neon line — sized for 10mm
Power suppliesMatched to 12 V, waterproof first
