100-240VAC 50W 500-1750mA CC DMX Driver
Dimming interface :DMX512/PUSH DIM
Dimming range: 0-100%
Input voltage : 100-240VAC
Power factor : >0.99
Current Accuracy :±3%
Output voltage : 10-54VDC
CC output: 500mA-1750mA
Output power :5W-50W
working temperature :-30℃～55℃
Package Size :135x92x32mm(LxWxH)
Weight (G.W): 340g
With the RDM remote device management protocol,
Supports DMX512 signal bi-directional communication.
PWM digital dimming, no alter LED color temperature.
Dimming range: 0~100%, LED start at 0.1% possible.
Multiple current, wide voltage, compatible with a variety of LED lights.
Power factor > 0.99, Efficiency > 85%.
Short circuit / Over-temperature / Over load / Non-load protection.
Non-load output voltage 0V to prevent damages to LED caused by poor contact.
Class 2 power supply. Full protective plastic housing.
Compliant with Safety Extra Low Voltage standard.
Suitable for indoor environments.
