CV Power Repeater DIN-3011-12A
DIN-3011-12A CV Power Repeater(DIN rail/Screw dual-use)
Input signal PWM
Input voltage: DC12V~DC24V
Max load current: 12A ×1CH Max 12A
Max output power :144W/288W(12V/24V)
Output signal :CV PWM
working temperature :-30℃~55℃
Package Size :L114×W37×H70(mm)
Weight (G.W): 120g
