Product Information
Unlock unparalleled installation flexibility with the LEDNEON-ACCOR-05 Double-Head 360° Rotating Mounting Clip, the ultimate solution for securing high-voltage LED neon flex strips. Unlike standard static clips, this innovative bracket features a fully rotational head, allowing you to achieve perfect angles on curved surfaces, complex architectural details, and creative signage. Its robust, double-head design provides a secure grip on both the mounting surface and the light strip. Available in four distinct sizes—12mm, 14mm, 16mm, and 18mm—it offers broad compatibility with a wide range of LED neon products. Constructed from durable, waterproof materials, this clip is engineered for long-lasting performance in both indoor and outdoor environments, ensuring your lighting installation remains stable and secure for years to come.
Key Features
Full 360° Rotation
Provides complete freedom to adjust the light strip's angle post-installation for precise directional lighting.
Versatile Size Options
Available in 12mm, 14mm, 16mm, and 18mm diameters to ensure a perfect fit for your specific high-voltage neon strip.
Double-Head Secure Design
One head mounts securely to the surface while the other firmly grips the neon strip, preventing sagging or displacement.
Weatherproof Construction
Made from high-quality, UV-resistant polycarbonate, making it ideal for durable outdoor and indoor applications.
Technical Highlights
- Enables complex installations on uneven or angled surfaces.
- Transparent material minimizes visual obstruction and shadow casting.
- Engineered specifically for the weight and profile of high-voltage LED neon strips.
- Simplifies maintenance by allowing easy removal and re-insertion of the light strip.
Product Specifications
| Parameter | Details |
|---|---|
| Product Model | LEDNEON-ACCOR-05 |
| Product Type | Mounting Clip / Fixing Bracket |
| Material | Polycarbonate (PC) |
| Rotation Angle | 360 Degrees |
| Available Diameters | 12mm, 14mm, 16mm, 18mm |
| Color | Translucent |
| Recommended Spacing | Every 30-50cm (1-1.5 ft) |
| Environment | Indoor / Outdoor Use |
Application Scenarios
How to Use This Mounting Clip
- Step 1: Choose the clip with the diameter that matches your LED neon strip.
- Step 2: Position the mounting-head of the clip onto the desired surface (wall, wood, ceiling).
- Step 3: Use an appropriate screw (not included) to securely fasten the clip to the surface.
- Step 4: Gently but firmly press your LED neon strip into the open, strip-holding head of the clip until it snaps into place.
- Step 5: Rotate the clip to adjust the neon strip to the desired angle.
- Step 6: For straight runs, install one clip every 30-50cm (1 to 1.5 feet) for optimal support. Use more clips for tight curves.
- Ensure you select the correct clip size for a secure fit. A loose clip will not hold the strip properly.
- Screws are not included. Please use screws appropriate for your specific mounting surface (e.g., wood screws, drywall anchors).
- This is a mechanical mounting clip, not an electrical connector. It provides no power or data connection.
- Do not overtighten the mounting screw, as this may damage the plastic clip.
What's in the Box
- ✓1 x Double-Head 360° Rotating Mounting Clip (in selected size)
Frequently Asked Questions
Q: Is this an electrical connector?
A:No, this is a mechanical mounting clip used to physically secure your LED neon strip to a surface. It does not conduct electricity.
Q: How do I know which size to order?
A:Measure the diameter or width of your LED neon strip and choose the corresponding size from the product options (12mm, 14mm, 16mm, or 18mm).
Q: Are these clips waterproof?
A:Yes, the clips are made from a durable, weatherproof polycarbonate material, making them suitable for both indoor and outdoor installations.
Q: How many clips should I use for my project?
A:We recommend placing one clip every 30-50cm (approximately every 1 to 1.5 feet) for straight runs. For curves or complex shapes, you may need to place them closer together.
Q: Do mounting screws come with the clips?
A:No, screws are not included. You will need to provide your own screws that are appropriate for the surface you are mounting to.
Q: Can I use this for low-voltage LED strips?
A:While designed for high-voltage neon strips, you can use them for any round or similarly shaped strip light that matches one of the available diameters.
