DC12-24V 10*23mm Top-Emitting Silicone Addressable Neon Digital LED Tube Light With WS2818 Dream Color Programmable Flexible LED Strip Lights, 5m/16.4Ft Per roll
1. Single row LED Neon Tube Light Flexible LED Strip Lights with 300 LEDs high power 5050SMD(Surface Mounted Devices)
2. Universal WS2818 dynamic color chasing, sequencing, changing, and also static color modes available on the Full-Color Controller and dream color Strip. individually addressable LEDs allow for sequencing modes.
3. Dome and flat Shape, Soft and easy bent for installation.
4. DC12/24V, a drop voltage of more than 5meters requires a separate power supply or use an amplifier.
5. Outdoor Use Waterproof IP67(silicone resin), food-grade silicone, safer and more environmentally friendly.
6. Life is longer than ordinary PVC Rubber Tube. Weather Resistance, Anti-UV, perfect heat dissipation.
7. 5meter(16.4') Per Reel By Sale.
DC12/24V 5-meter no voltage drop, but if you need a 20-meter DC12/24V neon light, in order to ensure that you use this light strips in the process of the front and behind the light of the same brightness, please supply power at both ends of each 10-meter.
Standards and Certifications
LED Strip Type: SMD 5050 Dream Color
LED Chip: WS2818 IC super brights Chip
Working Temperature: -4°F (-20°C) ~ 122°F (50°C)
Storage Temperature: -40°F (-40°C) ~ 176°F (80°C)
LED Quantity: 60 LEDs per meter
IC Quantity: 20 LEDs per meter
Dimensions: L500cm(196.8 in ) x W1.0cm(0.39 in ) x H2.3cm(0.90in )
Input Voltage(V): 12VDC
Working Power: 14.4W/3.28ft 72W/16.4ft
Lumen Per LED: 20-22Lumen 402lm Max /ft
Wavelength NM(RGBY): 2000-2500mcd
Beam Pattern: 120 degree
Water Proof: Waterproof IP67
Warantty: 3 years
5-meter neon lights without controller and power supply.
LED programmable digital display
Hotels decoration use
Concealed lighting, Cove decoration
Theaters, clubs, shopping malls lighting
Architectural decorative lighting
Boutique atmosphere lighting
Auditorium walk stairway lighting
Hidden groove, Wine cabinet decoration
Show exhibition decoration
