RGB LED Neon Color Changing Outdoor Lights Strip - DC24V - 16.4ft~65.6ft
LED Neon Strip vs LED Strip:
LED neon light strips (silicone sleeve tube housing) differs from ordinary SMD LED strip lights, which has good waterproof. LED neon flex strip light emits soft and delicate light, not blinding, and no light spot. Flexible LED neon tube light strip has the characteristics of energy-saving, environmental protection, no heat radiation is generated when working, no extra energy is lost, and LED neon lights do not produce any environmental pollution when used or discarded.
Flexible LED neon light strip is soft, bendable, knotted at will, and can be bent at will to make LED neon signs for exterior decoration and billboards, etc. It can work normally below 60 degrees Celsius, can be lit in daylight without yellowing, and works normally in rain and other environments.
Replacing traditional glass LED neon lights, this flexible LED neon strip light (adopts 05*15 LED silicone tube and RGB LED strip) stands out from other LED lights and brings you the most satisfying decorative lighting effect.
1. Suitable for outdoor decorative lighting, this LED neon lights strip is wrapped with high quality silicone material on the outside, and both ends of the LED neon strip adopts LED fast connector + waterproofing dealing with good water resistance to meet the lighting needs in outdoor environment.
2. No stinging sensation, the super bright light spot produced by the LED strip is softened by the 0.7mm thick milky white silicone tube, emitting a softer and more uniform glow, with no stinging sensation for direct eye contact, suitable for backlighting or positively exposed lighting projects
3. Work with LED controller, you can achieve single color gradient effect in dynamic and static mode, you can achieve precise color control via samrtphone app, Amazon Alexa, Google Assistant or LED remote controller(compatible with WL5 LED controller).
4. Easy to install, you only need to use a LED power supply and a LED controller connected at one end to control a 20m long LED neon light strip easily without voltage drop, avoiding complex wiring structure and making installation more convenient.
5. Meet customization requirements, complete 5/10/15/20m reel options are available.
Standards and Certifications
|LED Strip Type:||LED Neon Light Strip|
|LED Chip:||SMD 5050 Epistar Chip|
|Working Temperature:||-4°F (-20°C) ~ 122°F (50°C)|
|Storage Temperature:||-40°F (-40°C) ~ 176°F (80°C)|
|Dimension:||16.4ft-65.6ft/roll, every 6 PCS LED can be cut|
|LED Quantity:||60 LEDs per 1meter (3.28 ft), 18LEDs/Ft|
|Input Voltage(V):||24V DC|
|Input Current(A):||0.1A/Ft, 1.67A/16.4Ft, 3.33A/32.8Ft, 5A/49.2Ft, 6.67A/65.6Ft|
|Working Power:||8w/m, 40W/16.4Ft, 80W/32.8Ft, 120W/49.2Ft, 160W/65.6Ft|
|Lamp Luminous Flux(lm):||24~26lm/LED, 7200lm/16.4Ft, 14400lm/32.8Ft, 21600lm/32.8Ft, 28800lm/65.6Ft|
|Beam Pattern:||120 degrees|
|Waterproof:||Waterproof IP67(silicone tube)|
For indoor environment, If you choose the LED controller in the kit, we will send you YL5/WL5 (support samrtphone app, Amazon Alexa, Google Assistant control)
For outdoor environment, if you choose the waterproof LED controller in the kit, we will send you WL5-WP(waterproof 5in1 RGBCCT, support Amazon Alexa, Google Assistant control)
As the length of the LED strip increases, its power will decrease a little. The power supply of MeanWell UL-Listed LED power supply and waterproof LED power supply is the actual power, so 264W power can be selected as 250W LED power supply but needs to be greater than the rated power.
|Neon Strip Length||Non-waterproof LED Power Supply||Waterproof LED Power Supply|
Cove LED lighting
Retail LED lighting
Display case LED lighting
Accent LED lights
Under cabinet lighting
|By : Malcolm Harris Date Added: 10/03/2021|
|Nice! I installed this RGB neon tape under the escalator in the subway station. Its colors are amazing. I can’t feedback on the pictures here.|
|By : Anonymous Date Added: 09/25/2021|
|Amazing!! I built out a karaoke room after buying my house and felt like a neon sign would be the finishing touch. It was exactly what I wanted and looks absolutely amazing. I get compliments on it every time anyone comes over. Thank you so much!|
