Product Information
Experience effortless and precise lighting control with the MiBoxer FUT087-B Touch Dimming Remote Controller. Designed for simplicity and elegance, this handheld remote provides intuitive, stepless brightness adjustment for your single color or CCT LED lighting systems. Its minimalist design fits comfortably in your hand, while the sensitive touch panel offers a seamless user experience. Utilizing robust 2.4GHz RF technology, this remote controller for LED light ensures reliable performance over a distance of up to 30 meters without requiring a direct line of sight. It's the perfect solution for anyone seeking a straightforward, high-quality remote light switch to manage accent lighting, task lighting, or general illumination with finesse and ease.
Key Features
Intuitive Touch Interface
Effortlessly adjust brightness with a smooth, responsive touch-sensitive control panel for precise dimming.
Long-Range 2.4GHz RF
Control your lights from up to 30 meters (98.4 ft) away with a stable, non-directional wireless signal.
Sleek, Ergonomic Design
A modern, minimalist black finish and comfortable handheld shape make it both stylish and easy to use.
Ultra-Low Power Consumption
With a standby power of only 10uA, the two AAA batteries provide exceptionally long life.
Broad MiBoxer Compatibility
Pairs seamlessly with a wide range of MiBoxer and Mi-Light single color and CCT wireless LED controller receivers.
Technical Highlights
- Utilizes GFSK (Gaussian Frequency-Shift Keying) modulation for stable, interference-resistant signal transmission.
- Operates within the global 2.4GHz ISM band for reliable connectivity.
- Engineered for energy efficiency with an extremely low 10uA standby power draw.
Product Specifications
| Parameter | Details |
|---|---|
| Model | FUT087-B |
| Working Voltage | 3V (2x AAA Batteries, not included) |
| Transmission Technology | 2.4GHz RF Wireless |
| Transmission Frequency | 2400-2483.5MHz |
| Modulation Method | GFSK |
| Transmitting Power | 6dBm |
| Standby Power Consumption | 10uA |
| Control Distance | 30m (approx. 98.4 ft) |
| Operating Temperature | -20 to 60℃ |
| Compatibility | MiBoxer / Mi-Light 2.4G Single Color & CCT Controllers |
Ideal Application Scenarios
How to Use The FUT087-B Remote Controller
- Unscrew the back cover and insert two AAA batteries, observing correct polarity.
- To link the remote, first power off your compatible MiBoxer LED controller receiver for 10 seconds, then power it back on.
- Within 3 seconds of the receiver powering on, press the 'ON' button on the remote three times quickly.
- The connected LED lights will blink three times to confirm a successful link.
- Use the touch panel to slide your finger and adjust brightness. Tap the ON/OFF buttons for quick control.
- This remote requires a compatible MiBoxer/Mi-Light 2.4G RF receiver to function; it does not connect directly to an LED strip.
- The 30m control distance is measured in an open area. Walls, furniture, and other electronic devices may reduce the effective range.
- Batteries are not included with the remote controller.
- For detailed pairing instructions for your specific receiver, please refer to the receiver's user manual.
What's in the Box
- ✓1 x FUT087-B Touch Dimming Remote Controller
- ✓1 x User Manual
⇩ Downloads & Documents
PDFFUT087
Frequently Asked Questions
Q: What is the difference between the FUT087 and this FUT087-B model?
A:The FUT087-B is a specific model variant in the MiBoxer series. While functionally similar, always refer to the datasheet in the Downloads section to ensure compatibility with your existing controller receiver.
Q: Can I use this remote controller for RGB or RGBW LED lights?
A:No, the FUT087-B is a dedicated dimming remote designed for single color or CCT (tunable white) LED strip lights. It does not have color-changing functions.
Q: Does this mi light remote controller require a WiFi connection?
A:No, this is a 2.4G RF remote. It communicates directly with a compatible RF receiver without needing a Wi-Fi network, hub, or smartphone app.
Q: How do I pair (link) this remote with my lights?
A:Pairing involves powering on your LED controller and quickly pressing the 'ON' button on the remote three times within 3 seconds. The lights will blink to confirm success. Always check your controller's manual for specific steps.
Q: What is the real-world control range?
A:The remote is rated for up to 30 meters (about 98 feet) in an open environment. The range can be affected by physical obstacles like walls and electronic interference.
Q: What kind of batteries does the FUT087-B remote use?
A:It is powered by two standard AAA batteries, which are not included. Its energy-efficient design provides a very long battery life.
Q: Can I control multiple separate lights or zones with one remote?
A:The FUT087-B is a single-zone remote. It will control all linked receivers as one group. For multi-zone control, please consider models like the FUT089 or FUT092.
