V2-K 4CH*4A 12-24VDC Constant Voltage 4 Knob Color Temperature Controller
● CCT constant voltage LED RF controller, can also be used as a CCT RF remote.
● 4 knob dimming, digital numeric display and easy key operation.
● Match with RF 2.4G single zone or multiple zone color temperature remote control optional.
● 256 levels 0-100% dimming smoothly without any flash.
● PWM frequency 250/500/2000/8000Hz selectable.
● Logarithmic or linear dimming curve selectable.
4 Knob Controller Work as CCT RF remote
This 4 knob controller work as CCT RF remote can match with one or multiple CCT LED RF controller.
End user can choose the suitable match/delete ways. Two options are offered for selection:
Use the controller’s Match key
Short press match key of receiver,immediately press on/off key on the knob controller.The LED indicator fast flash a few times means match is successful.
Press and hold match key of the receiver for 5s to delete all match,The LED indicator fast flash a few times means all matched RF remotes were deleted.
Use Power Restart
Switch off the power of the receiver, then switch on power again, immediately short press on/off key 3 times on the knob controller.The light blinks 3 times means match is successful.
Switch off the power of the receiver, then switch on power again, immediately short press on/off key 5 times on the knob controller.The light blinks 5 times means all matched remotes were deleted.
Input and Output
Input Voltage: DC12-24V
Output Voltage: 4*DC12-24V
Input Current: 16.5A
Output Power: 4X(48-96)W
Output Type: Constant voltage
Input Signal:Konb+Key+RF 2.4GHz
Control Distant:30m(Barrier-free space)
Dimming Level: 256 levels
Dimming Range: 0 -100%
Dimming Curve: Logarithmic or linear
PWM Frequency: 250/500/2000/8000Hz
Warranty and Protection
Warranty: 5 years
Protection: Reverse Polarity
Safety and EMC
EMC Standard (EMC): EN301 489,EN 62479
Safety Standard(LVD): EN60950
Radio Equipment(RED): EN300 328
Standards and Certifications
3 Keys Setting
Short press: Turn on or turn off all 4 channel / zone light. When light is off, display "OFF".
Long press 5s: Enter RF remote matching state, display "RLS",within 5s, press any zone key of the 4 channel dimming RF remote, display "RLO", match is successful,
Long press 10s: Until display "RLE", delete all matched RF remote.
Long press 15s: Restore factory default parameter, display"RES".
Short press: Recall the scene 1, display"1-C".
Long press 2s: Save current state into scene 1, display"1-d".
Long press 5s: Prepare for setup output PWM frequence, then short press Scene1 key to switch between250Hz("F02"), 500Hz("F05"), 2000Hz("F20") or 8KHz("F80"). Higher PWM frequency,will cause lower output current, higher power noise, but more suitable for camera(No flickers for video).
Long press Scene1 key for 2s or timeout 10s, quit output PWM frequence setting.
Short press: Recall the scene 2, display"2-C".
Long press 2s: Save current state into scene 2, display"2-d".
Long press 5s: Prepare for setup output brightness curve, then short press Scene2 key to switch between linear curve("C-L") or logarithmic curve("C-E").
Long press Scene2 key for 2s or timeout 10s, quit output brightness curve setting.
