DC24V 35/24mm 6LEDs 360degree,20/40/50balls/string, Addressable LED pixel string, 3D LED Glowing ball light , 3D luminous ball, point light source
1. These products are made by SMD3535 RGB high brightness LED with big view angle
2. Use Taiwan Epistar chip，with high brightness，light color consistency，Good color saturation， Strong stability etc
3. Work at DC24V safety voltage，long lifespan，little luminous decay，Energy saving.
4. Use AB epoxy glue sealing, good compressive strength, high waterproof grade.
5. Cables and case are using anti-cold，flame retardant material，can be used for outdoor for a long Time
6. It is a new type energy conservation and environmental protection lights for decoration
7. Application: bridges decoration, hotels decoration， KTV, advertising, night clubs, shopping malls, offices front, bars and theme parks decoration etc.
Standards and Certifications
Product diameter: 35MM/24MM
Product voltage: DC24V
Product power: 1.5W / piece
LED quantity: 6LEDs/pcs
IC model number: UCS512/UCS1903
Waterproof performance: IP20 Non-waterproof Or IP68 Glue sealing waterproof
Packing: 20/40/50pcs per string
Operation temperature: -20 degrees to 60 degrees
Housing Material: Engineering plastic
Color: Full RGB color, 24bit, 256 gray scale
Beam angle: 360degree 3D Full color
Control protocol: SPI/DMX
Lifespan: 30000 hours
Please note that if the product requires a tee, use a 4-core cable, the output is not required. If the product does not require a tee, use a 3-core cable. The input and output require a waterproof connector.
1 The output voltage of the constant voltage power supply must not exceed the rated voltage, otherwise, it will cause damage to the lamp.
2 It is necessary to use the LED power source with the product supporting, not the supporting power supply may cause the lamp to be damaged.
3 Eye Protection Advice: Do not look directly into the light source when the LED is shining, especially for some LEDs with higher luminous intensity. Please be careful.
