Wall-Mounted DALI 4 Push Button Dimmer Master DA-4S
4 Push Button DALI Dimmer DA-4S. 1-4 Push button input / Encoding switch select addresses.
● Standard DALI Master, control 4 DALI Addresses.
● Comply to Latest DALI standard protocol IEC62386 and in compliance with DALI products from other international incorporation.
● Power is provided by DALI bus.
● 1-4 push button control.
● Enable to select of 4 different addresses for controlling by encoding switch.
● Support scene, group, unicast and broadcast mode.
● Easy to be placed in a standard wall junction box behind a push switch.
Standards and Certifications
|Input signal:||4xpush switch signal|
|Output signal:||DALI signal|
|Power supply:||DALI bus|
|Operation temperature:||Ta: -20℃ ~ +50℃|
|Case temperature (Max.):||Ta: +55℃|
