Product Information
The LTECH F5-DMX-4A is a hybrid constant-voltage controller engineered for multi-channel architectural and entertainment lighting. Operating across a wide 5–24V DC input range, it drives up to 4A per channel across 5 independent output channels (20A total current, delivering up to 480W at 24V). This dual-mode unit functions simultaneously as a hardwired DMX512/RDM decoder and an RF 2.4GHz wireless dmx receiver. Whether integrated into a wired DMX console line or paired wirelessly with EX series touch panels, F series handheld remotes, RC4-RF-B remotes, or a WiFi-106 gateway, the F5-DMX-4A provides stepless PWM dimming from 0.1% to 100%. Built for single-color, tunable white, RGB, RGBW, and RGBWW/RGBWY 5-in-1 LED strip installations, it provides reliable output control without visible flicker.



Core Technical Capabilities
Dual-Mode Wired and Wireless Input
Combines a standard DMX512/RDM hardwired bus with an integrated 2.4GHz RF wireless receiver for versatile jobsite configuration.
5-Channel Output Architecture
Delivers 4A across 5 independent channels to manage single-color, CCT, RGB, RGBW, or RGBWW low-voltage LED strip lights.
Deep 0.1% Dimming Floor
Achieves smooth, stepless PWM output from 0.1% to 100% without stepping, buzzing, or abrupt cutoffs at low light levels.
Substantial 480W Capacity
Handles 20W to 96W per channel at 5V to 24V DC, accommodating total electrical loads up to 480W on a single 24V supply run.
RDM Bi-Directional Management
Allows remote console querying and parameter assignment across standard DMX lines without requiring manual physical access to the driver.
Ecosystem Compatibility
Pairs directly with LTECH EX series in-wall panels, F series remotes, RC4-RF-B remotes, and WiFi-106 app gateways via on-board ID learning.
Engineering and Control Highlights
- Hybrid architecture functions as both a hardwired DMX/RDM decoder and an RF 2.4GHz receiver within a unified L175×W44×H30mm housing.
- 5-channel terminal design allows seamless assignment to DIM, CCT, RGB, RGBW, and RGBWW/RGBWY constant voltage linear arrays.
- Wide 5V to 24V DC working range matches low-voltage systems across 5V micro tape, 12V strip lights, and standard 24V commercial runs.
- Equipped with dedicated hardware ID learning button for rapid RF matching and factory code clearing within 10 seconds.
- Wide operating temperature rating from -30℃ to 55℃ ensures stability in unconditioned electrical panels and ceiling cavities.

Technical Specifications
| Parameter | Details |
|---|---|
| Model | F5-DMX-4A |
| Control Interfaces | DMX512 / RDM (wired) + RF 2.4GHz (wireless) |
| Input Voltage | 5-24VDC |
| Output Voltage | 5-24VDC (matches power supply voltage) |
| Output Channels | 5 Channels |
| Current Load | 4A × 5CH (Max. 20A total) |
| Output Power Range | (0-20W...96W) × 5CH, Max. 480W total |
| Dimming Range | 0-100%, minimum start at 0.1% |
| Operating Temperature | -30℃ to 55℃ |
| Product Dimensions | L175 × W44 × H30 mm |
| Mounting Hole Spacing | 170 mm |
| Package Size | L178 × W48 × H33 mm |
| Gross Weight | 130 g |
| Compatible Transmitters | WiFi-106 Gateway, EX Touch Panels, F Series Remotes, RC4-RF-B |
| Load Compatibility | Single Color, CCT Tunable, RGB, RGBW, RGBWW / RGBWY LED Strips |

Where to Deploy the F5-DMX-4A
How to Control & Use This Controller
- Step 1: Check your constant voltage power supply output (5V, 12V, or 24V DC). Connect the DC positive and negative leads to the 5-24Vdc power input screw terminals on the driver.
- Step 2: Connect your LED strip load to the 5-channel output terminals. Wire the common anode (V+) to the positive terminal, then connect the cathode channels (R, G, B, W, Y/WW) to terminals 1 through 5.
- Step 3 (Wired DMX Setup): Connect DMX IN and DMX OUT cables to the corresponding DMX data terminals (D+, D-, GND) on the driver bus, ensuring proper polarity throughout the daisy chain.
- Step 4 (Wireless RF Pairing - Method 1): Press the on-board 'ID learning button' once. The connected lamps will flicker. Within 10 seconds, press the ON key on your RC4-RF-B remote, or press any key / zone button on your F series remote or EX touch panel. Lamps staying solid confirms successful pairing.
- Step 5 (Wireless RF Pairing - Method 2): Cycle power to the driver on and off 3 times continuously until the lamps flicker. Within 10 seconds, activate the match button on the remote, touch panel, or WiFi-106 app color slider.
- Step 6 (Clearing RF Codes): Hold down the ID learning button for 10 seconds, or cycle input power 10 times consecutively. The connected LED strip will flicker 5 times to confirm code clearance.
- Step 7: Perform functional testing by cycling brightness levels from 0.1% to 100% and validating smooth color transitions across all 5 channels.
- Ensure the DC power supply output voltage matches the operating voltage rating of the connected LED strip lights exactly.
- Do not exceed the maximum current threshold of 4A on any single channel or 20A across all five combined channels.
- Always calculate power loads with a 20% safety margin: maintain continuous 24V loads under 384W (80% of 480W maximum).
- Maintain adequate air circulation around the enclosure; do not install in sealed unventilated spaces when operating near the 55℃ limit.
- Terminate the end of long wired DMX lines with a 120-ohm resistor across D+ and D- to prevent signal reflection.
What's in the Box
- ✓1 × LTECH F5-DMX-4A 5-Channel LED Wireless & Wired Driver
- ✓1 × User Instruction Manual
⇩ Downloads & Documents
PDFF5-DMX-4A
Frequently Asked Questions
Q: what is an led driver and how does the F5-DMX-4A function?
A:An LED driver regulates electrical power to LED lighting. The F5-DMX-4A functions as a constant-voltage PWM driver and decoder, converting incoming 5-24V DC power and DMX512 or 2.4GHz RF control signals into 5 regulated output channels for LED strip lights.
Q: what does an led driver do in a dual wired and wireless setup?
A:It translates control protocols into variable PWM duty cycles. The F5-DMX-4A receives wired DMX/RDM commands from physical console lines or RF signals from compatible remotes, synchronizing both inputs to adjust brightness and color.
Q: how to wire led strip lights to the 5 output channels?
A:Connect the positive feed wire of the LED strip to the V+ terminal, then secure the ground wires for each individual color (Red, Green, Blue, White, and Warm White) into output terminals 1 through 5.
Q: how to test led driver operation before final installation?
A:Connect a multimeter set to DC volts across the power input terminals to confirm correct supply voltage (5-24V DC). Next, connect a short LED strip, press the ID learning button to enter test mode, and verify that the strip illuminates and dims via your remote or DMX console.
Q: Can I use the F5-DMX-4A with 12V and 24V LED strip lights?
A:Yes. The unit accepts any DC input between 5V and 24V. When using 12V LED strips, connect a 12V DC power supply; when using 24V strips, connect a 24V DC power supply.
Q: What is the maximum wattage load this driver can handle?
A:At 24V DC, the driver supports up to 96W per channel (480W total across 5 channels). At 12V DC, it handles up to 48W per channel (240W total). At 5V DC, it provides up to 20W per channel (100W total).
Q: What remotes and wall panels are compatible with the wireless RF mode?
A:The F5-DMX-4A pairs with LTECH EX series touch panels, F series handheld remotes, the RC4-RF-B remote, and the WiFi-106 gateway for mobile app control.
Q: Does this driver support RDM configuration?
A:Yes. The unit supports the DMX/RDM protocol, allowing an RDM-compliant lighting console or programmer to remotely assign DMX addresses and query driver operating parameters.
