DC3V 4 Zones of RGB+CCT Touch Wall Panel RF Remote Control For RGBWW Zigbee LED Lights and Controller
Production Introduction :
1. GLEDOTPO led wall panel remote controller, which can control all GLEDOPO PLUS series LED products;
2. Power supply mode: 2 * AAA batteries (DC3V);
3. Installation method: paste the double-sided 3M adhesive backing we provide on the reverse side and paste it on the wall, which is convenient and quick.
4. Compatible with RGB+CCT WiFi controller and the entire Zigbee LED light system;
5. The remote looks fashionable and elegant, with simple and practical functions of color changing and brightness dimming, the capacitive touch screen design makes the remote easy to use.
6. The modular design and easy screwed terminals enable the controller easy to match with all kinds of led light products.
Type: Constant voltage source
Power consumption: 95
Number of channels: 4 zones
Working Temperature: -20-60℃
Transmitting Power: 6dBm
Input Voltage: DC3V (2*AAA battery)
Control Distance: 30m/100ft
Radio Frequency: 2400-2483.5MHz
Standby Power: 15uA
Modulation Method: GFSK
Product volume: 11.0 cm * 11.0 cm * 3.0 cm
