Mini LED fantastic controller SPI-16S+M16S
SPI-16S is a Mini LED pixel controller, equipped with RF remote M16S, almost able to control all IC-driven
LED lights. Compact and powerful, various built-in changing effects and customized scene modes can bring
By RF remote control M16S, you can select from a variety of dynamic lighting effects, set controlled pixels
quantity, adjust the changing speed and brightness, change the lighting moving direction, adjust RGB
sequence, select the IC type, store and play customized scene etc.
Power Input: 5~24Vdc
Wireless Signal: RF 2.4GHz
Working Temperature: -30 ~55
Working Voltage: 3V (battery CR2032)
Wireless Signal: RF 2.4GHz
Changing Mode: 16 kinds
